6306 Bearing Puller

$55.00

OUT OF STOCK UNTIL LATE DECEMBER 2024.    Fritz 70 – VW Type 1 Swing Rear Axle 6306 Bearing Puller.   *Must Use the factory rear axle spacer (not included)*

All type 1 Beetle/ Ghia/ Type 3 – Crashbox, Split Case, Tunnel – Short and Long (68 & Type 3) Axles.  Some Porsche 356.

Out of stock

SKU: FCP-70 Category:

Description

Introducing a new VW tool from Fritz Custom Products. A budget friendly 6306 specific bearing puller for Swing Axle VWs and Porsche 356s – works on type 1, type 3, Ghia – Split case, Tunnel case and both long and short Splined axles!

This 2 armed puller has ends that are specificly shaped to bite into the 6306 and once engaged cannot slip out – note* you must use the existing factory installed axle spacer as the fulcrum point to function properly (see pictures).

The Forcing Screw end is pointed to fit into the axle end and it swivels- staying centered not walking off and preventing damage to the threads.

The Arms are laser cut from AR500 1/4″ Steel Plate the hardest material I could find – its stronger than Chromoly. Due to the forces involved and nature of the the parts being used on, the tips can deform.  replacement arms are available.  Attempting to fixing/ reform the tip by hand will be difficult and likely not end in a usable result. Consider picking up an extra arm at time of order to save on shipping costs.

To Keep this budget friendly, it only uses 2 arms. I also only deburr the arms and sand lightly on them so they are a little cosmetically challenged from the deeper mill scale pitting and are left raw. You can polish them, oil them or prep and coat them to your liking.

https://youtu.be/IYdNL_gLnCw?si=RSobdFJhEEHL__ti&t=146
Wicked Werks YouTube Channel Did a nice little how to video on rear axle bearing replacement, and has a nice shot of the tool in action.

Additional information

Weight 2 lbs
Dimensions 8 × 1 × 4 in
